Concealed screw fitting:
• Suits door thickness:
- Entrance 35-55mm
• Suits a 54mm standard hole
• 60mm backset
• Entrance set key is 3 pin

Dimensions:
• Square backplate:
- 65mm x 65mm - internal diameter 52mm
• Finger-pull:
- 24mm base diameter - 29mm top diameter
Recessed depth 18mm
Suits a 25mm diameter hole

Key to lock and unlock from external side.

Finishes: BL- Matt Black, CP - Polished Chrome, SC - Satin Chrome

Unfortunately this lock can not be keyed alike to match other locks.
